Project Snapshot
PRISM Project #04-1034 (Completed)
Hart - Curley Creek Trib

Collapse All

    Project Details
Mid-Puget Sound Fish Enh Grp; Hart - Curley Creek Trib (#04-1034) Attachment #12534, Final Inspection
Mid-Puget Sound Fish Enh Grp; Hart - Curley Creek Trib (#04-1034) Attachment #12534, Final Inspection

Mid-Puget Sound Fish Enh Grp; Hart - Curley Creek Trib (#04-1034) Attachment #12534, Final Inspection Mid-Puget Sound Fish Enh Grp; Hart - Curley Creek Trib (#04-1034) Attachment #6437, Downstream end of culvert
Project Status:  Closed Completed since 06/22/2006

Project Type:  Restoration
Project Sponsor:  Mid-Puget Sound Fisheries Enhancement Group
Funding Board:  Recreation and Conservation Office
              Funding
FFFPP Grants: $30,400
Total RCO Grant: $30,400 (100%)
Total Agreement: $30,400 (100%)
              Links


    Project Description
Replace the existing barrier culvert with a new culvert using the WDFW No-Slope Design Option. Recommended specifications call for an aluminized pipe arch (squash) measuring 40 feet long by 95 inches wide, by 67 inches high. This new culvert will improve fish passage at the site while meeting the 100-year flood and debris flow needs. A squashed culvert is recommended for this site due to the shallow road fill depth, and to allow clearance under the existing waterline. This project will open up approximately 1/4 mile of stream habitat of which approximately 70% is classified as rearing, and 30% spawning area.

    Project Contacts

Project Sponsor: Mid-Puget Sound Fisheries Enhancement Group Lead Entity: West Sound Partners for Ecosystem Recovery
  Project Contact: Troy Fields

(206) 529-9467

Funding Agency: Recreation and Conservation Office
  Project Manager: Sandy Dotts
sandra.dotts@rco.wa.gov
(360) 628-9487

    Project Location
General Area:   near Long Lake
Waterbody:   Unnamed
County:   Kitsap
Legislative District:   26
Congressional District 2022:   06
Salmon Recovery Regions:   Puget Sound
Watershed Administrative Unit:   Clovos Passage/Carr Inlet
HUC8:   Puget Sound (17110019)
WRIA:   Kitsap
Sections:   08
Township:   T23NR02E
Coordinates:   47.49610065
-122.58144452

    Worksites
Worksite NameScope of WorkActual Restoration Cost
Hart (#1) Architectural & Engineering (A&E), Culvert installed or improved (C.2.f.1), Fish passage blockages removed or altered (C.2.c.1), Road-crossing removal (C.2.i.1) $4,361
 Total$4,361
Amounts may not be complete

    Properties
Worksite Name Property NameLandowner Type
Hart (#1)   Property 1 - Property - Worksite #1 Private
   Total
Amounts may not be complete

    Project Metrics (Outcomes, Benefits)
 Category / Work Type / MetricFinal

Restoration Metrics (rolled up from Worksite level)

Fish Passage Improvement
      Fish passage blockages removed or altered (C.2.c.1)
Number of Blockages/Impediments/Barriers Removed/Altered (C.2.c.2) 1
      Culvert installed or improved (C.2.f.1)
Miles of stream made accessible by culvert installation/repair (C.2.f.3) 0.26

Number of blockages / impediments / barriers impeding passage (C.2.b.4) 1

    Project Permits
Permit TypeApplied
Date		Received
Date		Expiration
Date		Permit Number
Hydraulics Project Approval [HPA]

    Project Milestones
Milestone NameTarget DateDescription
Project Start 08/01/2004
Data Design Forms Submitted 08/30/2004
Applied for Permits 08/30/2004
30% Design Review/Cost Check 08/30/2004
Bid Awarded/Contractor Hired 09/01/2004
Construction Started 09/05/2004
Construction Complete 09/30/2004
Agreement End Date 10/15/2004
Final Docs/Billing to Mgmt Agy 10/30/2004


    Project Attachments
Attachment TypeAttachment TitleAttach Date
Agreement - State FFFPP Agreement - 2 pgs..pdf 05/17/2007
Final project report Development/Restoration Project Final Report .pdf 05/17/2007
Inspection Photos Final - Fish.jpg 11/05/2004
Inspection Photos Final Upstream.jpg 11/05/2004
Inspection Photos Final Inspection - Road.jpg 11/04/2004
Inspection Photos Final Inspection.jpg 11/04/2004
Landowner application Hart application.pdf 07/02/2004
Photo Habitat upstream.jpg 02/03/2004
Photo Upstream end of culvert.jpg 02/03/2004
Photo Downstream end.jpg 02/03/2004
Photo Habitat downstream.jpg 02/03/2004
Photo Downstream end of culvert.jpg 02/03/2004
Site Plan: Restoration Site Plan 04-1034 Hart Property Private Rd. Culvert.pdf 11/04/2004
Watershed map WDFW WDFW Site Map.pdf 04/26/2004
Watershed map WDFW WDFW Watershed Map.pdf 04/26/2004
WDFW barrier & screening forms Final BEF and EBEF.pdf 03/29/2004
WDFW barrier & screening forms Level A.pdf 03/24/2004
WDFW barrier & screening forms Hart cost.pdf 03/24/2004
WDFW barrier & screening forms HartBEF.pdf 03/19/2004
