Koontz - Dogfish Creek Tributary R2
|
Mid-Puget Sound Fish Enh Grp; Koontz - Dogfish Creek Tributary R2 (#04-1545)
Attachment #8403, Koontz #2_downstream end
|
|
|
|
| Funding |
|
|
FFFPP Grants:
|
$35,792
|
|
|
Total RCO Grant:
|
$35,792
|
(100%)
|
|
Total Agreement:
|
$35,792
|
(100%)
|
|
|
This project will address a fish passage barrier on Dogfish Creek in Kitsap County. Located in WRIA 15 near Poulsbo, Dogfish Creek drains into Liberty Bay. Dogfish Creek supports coho, steelhead, cutthroat and searun cutthroat. The proposed action is to improve fish passage by replacing a culvert on a tributary to Dogfish Creek.
Two culverts currently exist on on the Koontz property connecting two tribitaries to Dogfish Creek. One is 11 foot in length, 2.4 feet wide and has collapsed in the middle collecting debris and acting as a partial barrier. The other culvert is 21 feet in length and almost entirely filled with sediment acting as a full barrier to fish migration. The tributatires are spring fed and flow perenially creating an additional .5 miles of stream for spawning and rearing habitat.
Mid Sound will replace one of the two culverts with a no-slope culvert option. the new culvert will be 40% countersunk and provide adequate fish passage. Dimension for the new culvert will be 101.5" X 76" X 20' in length.
|
|
General Area:
|
|
The point on the PRISM map is in the general vicinity, but should NOT be used for driving or other instructions...
|
|
County:
|
|
Kitsap
|
|
Legislative District:
|
|
23
|
|
Congressional District 2022:
|
|
06
|
|
Salmon Recovery Regions:
|
|
Puget Sound
|
|
Watershed Administrative Unit:
|
|
Liberty-Miller-Appletree
|
|
HUC8:
|
|
Puget Sound (17110019)
|
|
WRIA:
|
|
Kitsap
|
|
Sections:
|
|
02
|
|
Township:
|
|
T26NR01E
|
|
Coordinates:
|
|
47.77450441
-122.63994734
|
|
|
| Worksite Name | Scope of Work | Actual Restoration Cost |
|
Koontz - Dogfish Creek Trib. (#1)
|
Architectural & Engineering (A&E), Culvert installed or improved (C.2.f.1), Fish passage blockages removed or altered (C.2.c.1), Road-crossing removal (C.2.i.1)
|
$2,280
|
| | Total | $2,280 |
Amounts may not be complete
| Worksite Name | | Property Name | Landowner Type |
|
Koontz - Dogfish Creek Trib. (#1)
|
|
Property 1 - Property - Worksite #1
|
Private
|
| | | | Total |
Amounts may not be complete
| | Category / Work Type / Metric | Final |
Restoration Metrics (rolled up from Worksite level) |
Fish Passage Improvement |
| Fish passage blockages removed or altered (C.2.c.1) |
|
|
Number of Blockages/Impediments/Barriers Removed/Altered (C.2.c.2)
|
1
|
| Culvert installed or improved (C.2.f.1) |
|
|
Miles of stream made accessible by culvert installation/repair (C.2.f.3)
|
0.50
|
| |
|
|
Number of blockages / impediments / barriers impeding passage (C.2.b.4)
|
1
|
| Permit Type | Applied
Date | Received
Date | Expiration
Date | Permit Number |
|
Forest Practices Application [Forest & Fish]
|
|
|
|
|
|
Hydraulics Project Approval [HPA]
|
|
|
|
|
| Milestone Name | Target Date | Description |
|
Project Start
|
04/01/2007
|
|
|
30% Design Review/Cost Check
|
05/20/2007
|
|
|
Applied for Permits
|
05/30/2007
|
|
|
Bid Awarded/Contractor Hired
|
06/30/2007
|
|
|
Annual Project Billing Due
|
07/15/2007
|
|
|
Construction Started
|
07/30/2007
|
|
|
Construction Complete
|
08/30/2007
|
|
|
Agreement End Date
|
10/30/2007
|
|
|
Final Docs/Billing to Mgmt Agy
|
12/30/2007
|
|
